Popravila orodja na podlagi optičnih merilnih podatkov
Izziv
S preizkušanjem orodja želimo čim hitreje iterativno izdelati končno orodje. Orodje, ki bo v kompleksni interakciji materiala, orodja in stiskalnega stroja izdelalo dele, ki natančno izpolnjujejo konstrukcijske zahteve.
Rešitev
Z digitalizacijo orodja in poskusnih delov s sistemom ATOS lahko uporabnik pridobi vrednosti popravil. Te vrednosti lahko uporabi za revizijo zasnove in za specifično prilagoditev orodja.
Te informacije pokažejo, kje geometrija dela odstopa od modela CAD in kje ta odstopanja postanejo prevelika. Z njimi je mogoče analizirati elastično izravnavanje in natančno določiti ustrezno kompenzacijo. Obenem so na voljo podatki o tem, kako prilagoditi vzorec lukenj in obrezovanje.
