Urejanje mrež v programski opremi ZEISS INSPECT
Zagotovljena kakovost še pred pregledomS programsko opremo ZEISS INSPECT lahko zgladite, stanjšate in izboljšate poligonske mreže. Zapolnite lahko tudi luknje v mreži. Urejanje mrež je odvisno od ukrivljenosti in temelji na toleranci.
![Prikaz poligonskih mrež iz oblakov točk]({"xsmall":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_polygon-meshes-from-point-clouds.jpg/_jcr_content/renditions/original.image_file.100.56.0,0,746,420.file/zeiss_polygon-meshes-from-point-clouds.jpg","small":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_polygon-meshes-from-point-clouds.jpg/_jcr_content/renditions/original.image_file.360.203.0,0,746,420.file/zeiss_polygon-meshes-from-point-clouds.jpg","medium":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_polygon-meshes-from-point-clouds.jpg/_jcr_content/renditions/original.image_file.746.420.0,0,746,420.file/zeiss_polygon-meshes-from-point-clouds.jpg","large":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_polygon-meshes-from-point-clouds.jpg/_jcr_content/renditions/original.image_file.746.420.0,0,746,420.file/zeiss_polygon-meshes-from-point-clouds.jpg","xlarge":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_polygon-meshes-from-point-clouds.jpg/_jcr_content/renditions/original.image_file.746.420.0,0,746,420.file/zeiss_polygon-meshes-from-point-clouds.jpg","xxlarge":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_polygon-meshes-from-point-clouds.jpg/_jcr_content/renditions/original.image_file.746.420.0,0,746,420.file/zeiss_polygon-meshes-from-point-clouds.jpg","max":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_polygon-meshes-from-point-clouds.jpg/_jcr_content/renditions/original.image_file.746.420.0,0,746,420.file/zeiss_polygon-meshes-from-point-clouds.jpg"} "Poligonske mreže iz oblakov točk")
Ustvarjanje poligonskih mrež iz oblakov točk
ZEISS INSPECT iz 3D-oblakov točk izračuna 3D-mreže delov in komponent. Te mreže se uporabljajo za vizualizacijo, simulacijo, povratni inženiring in primerjavo med nazivnimi in dejanskimi vrednostmi. Primerne so tudi za virtualno sestavljanje na podlagi meritev iz različnih virov in jih je mogoče shraniti v običajnih formatih, kot so STL, G3D, JT Open, ASCII ali PLY. Mreže je mogoče tudi izvoziti v formatu STL za aplikacije, kot je 3D tiskanje.
![Urejanje mreže]({"xsmall":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_mesh-editing.jpg/_jcr_content/renditions/original.image_file.100.56.0,0,746,420.file/zeiss_mesh-editing.jpg","small":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_mesh-editing.jpg/_jcr_content/renditions/original.image_file.360.203.0,0,746,420.file/zeiss_mesh-editing.jpg","medium":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_mesh-editing.jpg/_jcr_content/renditions/original.image_file.746.420.0,0,746,420.file/zeiss_mesh-editing.jpg","large":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_mesh-editing.jpg/_jcr_content/renditions/original.image_file.746.420.0,0,746,420.file/zeiss_mesh-editing.jpg","xlarge":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_mesh-editing.jpg/_jcr_content/renditions/original.image_file.746.420.0,0,746,420.file/zeiss_mesh-editing.jpg","xxlarge":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_mesh-editing.jpg/_jcr_content/renditions/original.image_file.746.420.0,0,746,420.file/zeiss_mesh-editing.jpg","max":"https://www.zeiss.si/content/dam/iqs/r/software/zeiss-inspect/mesh-editing/zeiss_mesh-editing.jpg/_jcr_content/renditions/original.image_file.746.420.0,0,746,420.file/zeiss_mesh-editing.jpg"} "Urejanje mreže")
Urejanje mreže
Ustvarjene mreže lahko urejate tako, da jih zgladite, stanjšate ali izboljšate, zapolnite luknje ali odstranite krivine. ZEISS INSPECT vam v oknu za predogled prikaže stanje obdelave. Poleg tega lahko zlato mrežo določite tako, da poiščete najboljšo ali izračunamo povprečno mrežo. Po urejanju mreže lahko uvozite datoteke CAD in začnete 3D-pregled.
